High-pressure fog cannon raises the water pressure to hundreds of MPa through high-pressure pumps and atomises the water into tiny particles through nozzles, forming a fog-like water vapour. These tiny water mist particles are sprayed out under the action of the fan to cover a large area and adsorb, moisten and reduce the dust and pollutants in the air. The following Zheng Tong fog gun editorial for you to introduce the working principle of high-pressure fog cannon in detail.

First, the atomisation of water

The role of high-pressure water pump: high-pressure water pump is one of the core components of the high-pressure fog cannon, it can raise the water pressure to a very high level, usually hundreds of MPa. This high pressure makes the water when passing through the special nozzle, can be torn into very fine water mist particles, the diameter is generally between 10-50 microns.

Nozzle design: The design of the nozzle is critical to the atomisation effect. Its internal structure converts the high-pressure water stream into fine water mist particles that are evenly dispersed into the air. This design ensures that the water mist can quickly combine with airborne pollutants.

Second, the role of wind

Fans with: in the formation of water mist, you need to use the power of the fan will be sprayed out of these water mist, and cover a wider range. The size of the fan and the direction and size of the wind can be adjusted to ensure that the water mist can evenly cover the target area.

Jet power: The fan of the fog cannon not only provides jet power, but also helps the water mist to spread in the air and form a layer of coverage. This ensures that the water mist can float in the air for a long time and contact with more dust and pollutants.

Third, the water mist coverage

Large area coverage: due to the high pressure formed by the water mist particles are small and numerous, they can float in the air for a longer period of time and spread to a larger area, usually much larger than the traditional sprinkler coverage area. This large area coverage makes the fog cannon ideally suited for tasks requiring extensive cleaning such as urban road cleaning, construction site dust control and industrial exhaust treatment.

Dust removal mechanism: when the water mist comes into contact with the dust particles in the air, it will increase the weight of the dust particles by adsorption and wetting, thus prompting them to settle to the ground quickly to achieve the purpose of dust reduction.

High-pressure fog cannon through high-pressure pumps and special nozzles to atomise the water, and with the help of the fan will be widely sprayed out of the water mist, the use of fine water mist particles on the air pollutants adsorption and settlement. It has significant advantages in dust removal effect and coverage.
